Applicable scope：
It is widely used in the fields of electric power, metallurgy, mining, machinery, chemical industry, communications, manufacturing, food stuff for purification or regeneration of hydraulic oil, shafting oil, refrigerator oil, machine oil, die-casting oil, air compressor oil, gear oil, heat treating oil, anti-wear hydraulic oil, emulsified oil, high water content oil ect. waste oil or contaminated oil, as well as injection molding oil, cylinder oil, textile knitting oil, high speed machinery oil, high precision lube oil.
Product parameters
Item | Unit | ZJD-6 | ZJD-10 | ZJD-20 | ZJD-30 | ZJD-50 | ZJD-75 | ZJD-100 | ZJD-150 | ZJD-200 | |
Flow rate | L/H | 360 | 600 | 1200 | 1800 | 3000 | 4500 | 6000 | 9000 | 12000 | |
Vacuum degree | Mpa | -0.06 ～ -0.095 | |||||||||
Working pressure | Mpa | ≤0.4 | |||||||||
Working temperature | ℃ | 0 ～ 100 | |||||||||
Power supply | 380V/50Hz（or as per requirement） | ||||||||||
Heating power | kW | 9 | 15 | 18 | 30 | 45 | 60 | 96 | 120 | 135 | |
Total power | kW | 11 | 17 | 21 | 33 | 48 | 65 | 102 | 135 | 147 | |
Inlet&outlet size | mm | 15 | 25 | 25 | 25 | 32 | 42 | 50 | 50 | 60 | |
Weight | Kg | 350 | 500 | 550 | 600 | 750 | 850 | 1000 | 1500 | 2000 | |
Size(mm) | L(mm) | 1100 | 1300 | 1350 | 1350 | 1350 | 1400 | 1650 | 1750 | 1850 | |
W(mm) | 950 | 900 | 950 | 1000 | 1100 | 1100 | 1000 | 1400 | 1500 | ||
H(mm) | 1350 | 1600 | 1650 | 1650 | 1700 | 1750 | 1750 | 1950 | 2000 | ||
Oil index after treatment | |||||||||||
Demulsification value | min | ≤15min | |||||||||
Gas content | % | ≤0.1% | |||||||||
Water content | % | Trace(no) | |||||||||
Cleanness | NAS | ≤6 级 | |||||||||
Precision | µm | ≤5µm（or customer advice） | |||||||||
Advantages
1) Coalescence separation and vacuum dehydration are combined. The water separation device adopts the world's leading coalescence separation technology, which can quickly and efficiently separate a large amount of water and micro water from lubricating oil with high water content.
2) Strong ability to filter impurities, large area, deep layer, high-precision FH rectangular filter system, can effectively remove iron filings, dust and impurities in the oil.
3) Tongrui technology of H, P, M polymer adsorption materials. The use of high-quality original parts and connection sealing materials meets the requirements of high temperature for filtering high-viscosity lubricating oil, and expands the types and scope of oil that can be purified by the oil filter.
The stainless steel mat-shaped mesh filter material can be repeatedly cleaned and used, saving energy and reducing consumption, and can be effectively reused many times.
FAQ:
Q1:Packaging Shipping:
By sea, by air, by train, by truck, according to customers demands
Q2:What about the lead time for mass production?
usually small order 5~7work days, large order will needs about 30work days
Q3:What is your terms of delivery?
100% payment before delivery from seller factory
Q4：If we have some other product requirements that your page don't include, can you help to supply?
yes, we can.
Q5：Does your product have warranty service?
How long is the warranty period?"
12months after running the machine
Q6：How long is the delivery period of the product?
In stock goods, 1~2work days. Not in stock goods, 5~7work days.
Q7：What quality certifications do you have?
"ISO9001 quality certification
European CE security certificate"
